Aditeg AFC8300 Frequency Counter

• Frequency Counter Aditeg AFC8300 ( Frequency range 1 Hz ~ 3 GHz )
• Measuring range

1. Freq A : 1 Hz to 100 MHz
2. Freq B : 100 MHz to 3 GHz

• Period range 10 ns ~ 1 s
• Totalize capability 10 8 1
• Sensitivity

• 40 mV rms ( 1 Hz ~ 10 Hz )
• 20 mV rms ( 10 Hz ~ 100 MHz )
• 30 mV rms ( 100 MHz ~ 3 Hz )

• Input impedance 1 M Ω / 40 pF ( Channel A ) 50 Ω ( Channel B )
• Input Voltage

• 20 mV rms ~ 250 Vp-p ( Channel A )30 mV rms ~ 1 V rms ( Channel B )

• Couple mode AC
• Measure error ± Time base accuracy ± Trigger error x Measured frequency ( or Period ) ± LSD
• Time base stability ± 5 x 10 -6 /d
• Power Source 110 ~ 127 VAC ± 10% / 220 VAC ~ 240 VAC ±10% , 50 Hz ±2 Hz/ 60 Hz±2 Hz
• Dimensions Unit (WxHxD) 210 x 80 x 230 mm
• Made in China

 Jual Aditeg AFC8300 Frequency Counter dengan harga murah dan bergaransi resmi, dapatkan produk berkualitas dan terpercaya.Distributor alat uji,ukur,survey,geologi,telekomunikasi,gps dll. 100% Original.
